Temperature range: 5/22˚C.
Space for up to 46 bottles of wine – 133 l.
5 wooden shelves made of beech wood resistant to humidity level fluctuations.
Pull-out shelves.
Compact size – perfect for serving wine at the counter.
Energy class: G (A-G).

10 chrome-plated shelves.
Energy class: E (A-G).

Very easy in use, cleaning, maintenance and even servicing
.
Perfect for washing plates, cutlery, glasses, mugs, trays
.
Electromechanical controls.

Housing made of stainless steel AISI 304
.
Separate spray arms for washing (plastic) and rinsing (stainless steel
).
Fixed washing arms at the top, rotating stainless steel rinsing arms
.
Solid double-skin door
.
Washing cycles number/duration: 1/120 s.

Capacity: up to 30 baskets/h.

Water consumption per cycle: 2-2,5 l (depending on water pressure)
.
Washing water temperature: 62°C, rinse water temperature: 85°C
.
Boiler (capacity/power): 6 l/3 kW for 230V and 6 kW for 400V
.
Tank (capacity/power): 35 l/3,6 kW.

Pump power: 0,75 HP.

Safety thermostat for boiler/for tank up to 105°C/99°C
.
Analog water thermometer for boiler.

IP44 protection class.

Weight: 57 kg
.
EQUIPMENT:
 1x universal baskets 500x500x(H)105 mm for glasses
, 1x basket with pins 500x500x(H)105 mm for plates
, 1x cutlery basket 110x110x(H)130 mm
, water supply hose length 1,5 m with connection 3/4” inner thread
, drain hose length 2 m Ø 25 mm
, power cord without plug,
rinse aid dispenser
, adjusted for detergent pump installation (screw in tank rear wall). Vertically adjustable legs: ±10 mm, Ø 40 mm.

The appliance is designed for use in bars, pubs, cafes, and restaurants.
Robust housing made of AISI 304 stainless steel.
Plastic interior.
Air vents on the front of the housing to allow for under-counter installation of the ice maker.
The appliance uses spray method to mould perfectly clear cubes with the hexagonal hole that have larger cooling surface and ensure longer cooling time – while minimising beverage thinning.
Innovative method of heat exchange via an additional condenser – compressor heat recovery used for defrosting the spray plate.
Extended compressor performance and life.
Effective operation in ambient temperature of up to 42°C.
Low energy consumption.
Adjustment of the ice bin fill level.
Adjustable feet.
Easy cleaning thanks to removable parts.
Inlet & outlet hoses and ice scoop included.
Refrigerant: R454c.
Daily output: 40 kg.
Ice bin capacity: 16-18 kg.
Dimensions: 480×580×(H)750 mm.
Power/voltage: 455 W/230 V.
Net/gross weight: 44/47 kg.

Structure and handle made of stainless steel.
Suitable for dishes of max. capacity of 56 l.
Powerful 2,000 W motor.
Net weight: 4.2 kg.
Bag for safe transport of the appliance included (1180085).
Insulated tank GN 2/1 (H)200 mm for SmartVide 9 immersion circulator sold separately (1180065).
