Diameter, mm | 200 |
Product dimensions | 200x200x50mm |
Main material | metal |
Material | stainless steel |
Very easy in use, cleaning, maintenance and even servicing.
Perfect for washing mugs, cups, glasses, cutlery, plates.
Electromechanical controls
.
Housing made of stainless steel AISI 304
.
Separate stainless steel spray arms for washing and rinsing
.
Solid double-skin door
.
Washing cycles number/duration: 1/120 s
.
Capacity: up to 30 baskets/h
.
Water consumption per cycle: 2-2,5 l (depending on water pressure)
.
Washing water temperature: 62°C, rinse water temperature: 85°C
.
Boiler (capacity/power): 3,5 l/2,5 kW.
Tank (capacity/power): 17 l/2,5 kW.
Pump power: 0,1 HP.
Safety thermostat for boiler/for tank up to 105°C/99°C
IP44 protection class.
Weight 39 kg.
EQUIPMENT:
1x universal baskets 400x400x(H)150 mm for glasses
, 1x basket with pins 400x400x(H)110 mm for plates
, 1x cutlery basket 110x110x(H)130 mm
, water supply hose length 1,5 m with connection 3/4” inner thread
, drain hose length 2 m Ø 25 mm,
power cord without plug,
rinse aid dispenser,
adjusted for detergent pump installation (screw in tank rear wall). Vertically adjustable legs: ±10 mm, Ø 40 mm.
1391,10 €
Burners: 2x 6 kW + 2x 3.5 kW Suitable pots and pans: Ø 120-300 mm Thermocouple.
AISI 304 cooker top.
Side and back housing: AISI 430.
Cast iron grates 335x300 mm, one for each burner.
Cast iron burners.
GZ50 gas.
Extra LPG nozzles included.
No igniters or pilot flame – match-lit flame.
Steel feet with non-slip surface, with adjustment from 55 to 65 mm.
Weight: 35 kg.
1333,10 €
Coolant R134a.
Chamber dimensions: 565x640x(H)1525 mm.
3 Gastronorm 2/1 shelves included.
Weight: 110 kg.
1553,40 €
Display cabinet frame made of ABS+PVC polymers, with double glass.
Unit housing made of ABS.
5 shelves, dimensions 427x386x(H)8 mm.
Fitted with 4 wheels, 2 with brakes.
Energy label: C (A-G).
Temperature range: 2 to 8°C.
Refrigerant: R290.
1159,20 €
Suitable for natural gas.
Conversion set for propane gas included.
3 burners of 3.0 kW.
1 small burner of 1.8 kW.
1 wok burner of 3.5 kW.
Piezo ignition and thermocouple.
Three-part cast iron pan support.
Convection oven 1/1 GN with a capacity of 2.7 kW fitted with two ventilators, thermostat to 275°C and timer.
Includes 2 grids.
Additional upper element of 2.5 kW for grilling.
Stainless steel oven interior and inner door.
Weight: 78 kg.
1811,40 €
